Forklift bearing

Forklift bearing

The release date：[2015-07-07 09:08:28] Click rate：[1346] Source: Yiwu Hailin E-commerce Firm

FORKLIFT BEARINGS
FORKLIFT BEARINGS
轴承型号		类型	尺寸						圆弧R	额定负荷		备注
Bearing No.		TYPE	Dimensions(mm)						斜度α	Load Rating(kn)		Remart
Ⅰ	Ⅱ		d	D	C	B	R1	R2		Cr	Cor
30309		1	45	119	30	25	3	3	3。29‘	40.7	30.0
130309KT		3	45	118.5	26	25	5	5		40.7	30.0
130709	80709K	2	45	119	29	25	3.5	3.5		40.7	30.0
30710	80710K	1	50	115.3	34	25	3	3		33.3	25.1
30810K1	30810K	3	50	117.5	34	25	5	5	3。29‘	33.3	25.1
30211	T20211	1	55	112	34	21	5	5		33.3	25.1	2.5T
30211K	J20211	1	55	110	34	21	5	5		33.3	25.1	2.5T
30211K1	J30211	3	55	111.8	34	21	5	8	2。31‘	33.3	25.1	2.5T
30711H	80711K	1	55	110	31.3	21	3	3		33.3	25.1	2T
30711K1	80700Y	3	55	112.2	31.3	21	3	3	2。52‘	33.4	25.1	2T
30711K1-C	80711Y2	3	55	112.2	31.3	21	2	5	2。52‘	33.3	25.1	2T
30711K1-G	80711Y1	3	55	116	31.3	21	2	5	2。52‘	33.3	25.1	2T
30511	80511K	3	55	116	34	25	5	5	2。52‘	41.0	30.9	3T
30511K	80511K1	1	55	117	34	25	5	5		41.0	30.9	3T
30711	80511K2	1	55	120	34	25	5	5		41.0	30.9	3T
30511K1	80511Y1	1	55	121.5	34	25	5	5		41.0	30.9	3T
30511K1-C	80511Y2	3	55	122.5	34	25	5	8	2。52‘	41.0	30.9	3T
30511K1-G	80511Y	3	55	120	34	25	5	5	2。52‘	41.0	30.9	3T
30811K1	980811	3	55	121.4	36	25	5	8	2。52‘	41.0	30.9	3T
30311		1	55	151	45	33	4	4		54.9	41.8	4T
30411	80611K	1	55	161	42	33	5	5		77.1	61.4	4-6T
110306F	L10306F	4	30	77	23	19	3	5	R200’	21.6	14.8	1T
110306H	L10306H	4	30	78	23	19	3	5	R200’	21.6	14.8	1T

FORKLIFT BEARINGS
FORKLIFT BEARINGS
轴承型号		类型	尺寸							额定负荷		备注
Bearing No.		TYPE	Dimensions(mm)						斜度α	Load Rating(kn)		Remart
Ⅰ	Ⅱ		d	D	C	B	R1	R2		Cr	Cor
130304	L20304	2	20	60	16	15	2	2		12.3	7.8	0T,1T
30505	80505K1	1	25	70	27	15	2.5	2.5		10.8	7.0	1T
130205	80505K2	2	25	70	17	15	2.5	2.5		10.8	7.0	1T
30705	W20205	1	25	70	28	15	2.5	2.5		17.2	11.4	1T
30805	80505K	1	25	80	22	16	3	3		17.2	11.4	3T
30805K	180705	1	25	80	22	17	3	3		17.2	11.4	3T
30306		1	30	76	20	19	3	5		21.6	14.8
130306	80606K	2	30	78	23	19	3.5	3.5		21.6	14.8
130706	180706K	2	30	91.5	24	19	2	5		21.6	14.8
130706K		2	30	91.5	24	20	2	5		21.6	14.8
30806T	80506K	1	30	90	22	17	3	3		25.0	17.8	3T
30307		1	35	80	25	21	3	3		25.7	17.5
30307T	180707KT	2	35	102	25.5	21	2	5		25.7	17.8
30507	80507K	1	35	100	26	18	2	2		25.0	17.8
130607	80607K	2	35	102	25.4	20	3.5	3.5		25.7	17.5
30807	80307K	1	35	90	31.4	21	3	3		25.7	17.5
30208	80508K	1	40	116	24.5	18	3	3		25.0	17.8	1T-1.5T
30208K	80508K1	1	40	110	29	18	3	3		25.0	17.8	1T-1.5T
30208K1	80508Y1	3	40	112.3	29	18	3	3	2。30‘	25.0	17.8	1T-1.5T
30308	S20308	1	40	115	32	23	6	6		31.4	22.3	3T
30308S		1	40	111	30	23	3	10		31.4	22.3	3T
30308N		1	40	112	30	23	3	10		31.4	22.3	3T
30308L		1	40	113	30	23	3	10		31.4	22.3	3T
130308	80608K	2	40	104	27	23	3.5	3.5	3. 29’	31.4	22.3
130308KT		3	40	109.7	28	23	7	5		31.4	22.3
30708	80708K	1	40	109.7	32	23	3	7		31.4	22.3

FORKLIFT BEARINGS
FORKLIFT BEARINGS
轴承型号		类型	尺寸(mm)						额定负荷(kn)
I	II	类型	d	D	D1	C	C1	B	Cr	Cor
780306	L60306	1	30	96	80	24	16	19	21.6	14.8
780606K	L60606K	1	30	87	75	34	22	26	21.6	14.8
780506	780506K	1	30	134	115	32	22	26	36.4	26.7
780307		1	35	105	90	30	21	21	33.4	19.2
780308	F80308	1	40	120	110	40	30	23	31.4	22.3
780308K		1	40	140	120	34	27	23	31.4	22.3
780308K3		1	40	138	120	37	28	23	31.4	22.3
780308K4		1	40	142	124	34	27	23	31.4	22.3
780708		1	40	118	100	32	26	23	31.4	22.3
780708K		1	40	118	100	34	27	23	31.4	22.3
780708H		1	40	118	100	37	28	23	31.4	22.3
780708K1		1	40	113	95	32	21	23	31.4	22.3
780408	L60408	1	40	134	115	39	29	27	49.3	36.4
780309	S60309	1	45	138	125	58	34	25	40.7	30
780390K		1	45	126	110	36	25	25	40.7	30
780390K1	780309	1	45	126	110	47	37	25	40.7	30
780390K2		1	45	126	110	30	25	25	40.7	30
780390K3	A60309	1	45	126	110	44	34	25	40.7	30
780709	780709	1	45	126	110	38	28	25	40.7	30
780709K		1	45	125	110	35	25	25	40.7	30
780310H		1	50	148	134	41	25	27	47.6	35.7
780310K		1	50	141	122	46	27	27	47.6	35.7
780310K2		1	50	155	135	42	33	27	47.6	35.7
780310K3	780711K	1	50	151	135	44	35	27	47.6	35.7
780711	60211B	1	55	122	111	40	28	21	33.3	25.1
780711H		1	55	131	119	40	22	21	33.3	25.1
722711		2	55	144	122	56	43	40	77.4	62.7
780411		3	55	160	145	52	36	44.5	77.4	62.7
780415		3	75	218	200	65	49	53	112	76.8
